We are a Kenwood authorized dealer so you get up-to-date, fully warrantied products.
What's Inside?
•One 10" Subwoofer
•Eight 1-3/8" Screws
•Adhesive backed foam gasket
•Cardboard template
•Warranty information
•Specs on box lid
•Owner's Manual
Larger Cone Size
Low frequency output is increased because of a larger cone size. The cutout diameter has remained the same making this feature of the new XR woofers ideal for most vehicles where space is a premium. The XR woofers are ideal for a small sealed box.
Reinforcing Ribs (Cone)
The newly designed cone features ribbing that adds strength to the cone and minimizes distortion.
Strong Magnetic Circuit
Our engineers designed a strong magnetic circuit with the purpose of reproducing deep low frequencies. Their efforts employed a large magnet and optimized yoke.
Stress-free Spider
By adopting a "Stress-free Spider" and a "Thermal Efficient System" the mechanical and thermal durability has been improved dramatically delivering smooth and strong bass sound with long lasting reliability.
| Brand | Kenwood |
| Size | 10 -inch |
| Impedance (Ohms) | 2 |
| Cone Material | Polypropylene |
| Surround Material | Rubber |
| Sensitivity | 80 dB at 1 watt |
| Frequency Response | 31 - 300 Hz |
| Max RMS Power Handling | 300 |
| Peak Power Handling (Watts) | 1300 |
| Port diameter (inches) | N/A |
| Port length (inches) | N/A |
| Free-Air | No |
| Dual Voice Coil | No |
| Top Mount Depth (inches) | 4.8125 |
| Bottom Mount Depth (inches) | N/A |
| Cutout Diameter or Length (inches) | 9.0625 |
| Vas (liters) | 63.8 |
| Fs (Hz) | 24.1 |
| Qts | 0.394 |
| Xmax (millimeters) | 11.6 |
| Ideal Sealed Box Volume (cubic feet) | 0.55 |
| Minimum Sealed Box Volume (cubic feet) | 0.45 |
| Maximum Sealed Box Volume (cubic feet) | 0.76 |
| Ideal Ported Box Volume (cubic feet) | 0.9 |
| Minimum Ported Box Volume (cubic feet) | 0.7 |
| Maximum Ported Box Volume (cubic feet) | 1.24 |
| Parts Warranty | 2 Years |
| Labor Warranty | 2 Years |
