We are a Kicker authorized dealer so you get up-to-date, fully warrantied products.
What's Inside?
- 51LX1650.1
- LX Mono Customer Information Card
- LX Remote Control with Cable
- Mounting Hardware
- 3mm Hex Key
- Power Wire Cable Chart
- High level Input Harness (CEA Color Standard)
From the Ground Up
The LX-Series represents KICKER’s high-power premium amplifier line designed in-house from the ground up. Precision control, next-level flexibility, designed for performance, built to last.
- Monitor and adjust with the included LXRC Dash Remote
- Class-D design for lower current draw, longer playing times, and lower operating temperatures
- Gain-match LEDs show you perfect gain setting
- KickEQ+™ parametric bass boost 0–6dB
- Customize the appearance with reversible center panel and choice of 11 RGB LED accent colors
- Equipped with FIT+™ technology, accepting low- and high-level signals up to 40V, with differential inputs designed to eliminate unwanted noise for crystal-clear sound
- LX features choice of turn-on modes and comprehensive protections for thermal, circuit, and voltage stability, ensuring reliable performance
Comes with the LX REMOTE CONTROL (LXRC)
- Dynamic fingertip dash remote of bass level adjustment
- Features SHOCwave2.0™ (Sub-Harmonic Octave Creation), KICKER’s 2nd-gen digital bass restoration algorithm that recovers lost, low-bass frequencies vital to your music selections
- Displays battery voltage in fuel-gauge-style readout
- Control of its RGB LED brightness
- Output clipping indicator to prevent distortion and protect your system
- Cable Length – 19.75 feet (6m) RJ45 cable
| Brand | Kicker Sale Items |
| Channels | 1 |
| Power (@14.4V, <1%THD+N) | 4? 550W x 1 |
| Power (@14.4V, <1%THD+N) | 2? 1000W x 1 |
| Power (@14.4V, <1%THD+N) | 1? 1650W x 1 |
| Dynamic Power (@14.4V, <10%THD+N) | 1? 2200W |
| Lowest Rated Impedance | 1? |
| Signal to Noise Ratio (CEA) | 1W >-75dB |
| Signal to Noise Ratio | Rated Power >-95dB |
| CMRR | 50Hz -40dB |
| Input Impedance | >20k? |
| Frequency Response | 10Hz - 160Hz |
| Variable LoPass Filter | 24dB / Octave LR 40Hz - 160Hz |
| Variable Subsonic Filter | 24dB / Octave LR 10Hz - 80Hz |
| KickEQ+ Variable Bass Boost | 0dB - 6dB |
| KickEQ+ Variable Center Frequency | 20Hz - 80Hz |
| KickEQ+ Variable Bandwidth | 1 - 5 |
| Standby Current (Remote Off) | <2mA |
| Idle Current (Remote On) | <3A |
| Current Draw (Rated Power) | <150A |
| Remote Gain Attenuation (LXRC Included) | -26dB - 0dB |
| Low Level Input Sensitivity | 125mV - 5V |
| High Level Input Sensitivity | 1V - 40V |
| Under Voltage Protection | 6.5V (warning at 10.5V) |
| Over Voltage Protection | 16.5V (warning at 16V) |
| Active Thermal Management | >75°C |
| Width (inches) | 9.5 |
| Height (inches) | 2.375 |
| Depth (inches) | 8.4375 |
| Parts Warranty | 1 Year |
| Labor Warranty | 1 Year |
