What's Inside?
•One 12" SVC Woofer
•Rubber concealing ring (installed)
•Self-adhesive foam strip
•8 Mounting screws
•"Kenwood" logo sticker for woofer
•"eXcelon logo sticker for woofer
•Cardboard template
•Warranty Card
•Owner's Manual
Produces Serious Bass Output
The Kenwood Excelon KFC-XW1200F 12" "flat" subwoofer produces serious bass output in the hard-to-fit areas of your compact car or truck. And this shallow-mount sub measures less than 4" deep, so you can get creative with your installation.
The carbon-glass fiber cone employs a honeycomb pattern to deliver quick response in demanding conditions without flexing. The beefed-up rubber surround maintains control over the cone, minimizing distortion caused by resonance. A die-cast aluminum basket offers a rock-solid housing with plenty of venting to keep the heat down. The silver-plated push terminals offer convenient connections and provide excellent signal transfer.
| Brand | Kenwood |
| Size | 12 -inch |
| Impedance (Ohms) | 4 |
| Cone Material | Carbon-glass fiber |
| Surround Material | Butyl rubber |
| Sensitivity | 91 dB at 1 watt |
| Frequency Response | 30 - 700 Hz |
| Max RMS Power Handling | 350 |
| Peak Power Handling (Watts) | 1400 |
| Port diameter (inches) | 3 |
| Port length (inches) | 14 |
| Free-Air | No |
| Dual Voice Coil | No |
| Top Mount Depth (inches) | 3.9375 |
| Bottom Mount Depth (inches) | 4.4375 |
| Cutout Diameter or Length (inches) | 11.0625 |
| Vas (liters) | 62.69 |
| Fs (Hz) | 24.8 |
| Qts | 0.544 |
| Xmax (millimeters) | 8.5 |
| Ideal Sealed Box Volume (cubic feet) | 0.8 |
| Minimum Sealed Box Volume (cubic feet) | N/A |
| Maximum Sealed Box Volume (cubic feet) | N/A |
| Ideal Ported Box Volume (cubic feet) | 0.8 |
| Minimum Ported Box Volume (cubic feet) | N/A |
| Maximum Ported Box Volume (cubic feet) | N/A |
| Parts Warranty | 2 Years |
| Labor Warranty | 2 Years |
