We are a JL Audio authorized dealer so you get up-to-date, fully warrantied products.
What's Inside?
•Monoblock amplifier
•Power connector
•14" Analog Input harness (15-pin D-Sub/4 RCA)
•Subwoofer output connector
•18" Speaker wire loom
•"Sub" wire label
•6' USB cable (Type A USB on one end and Type B USB on other end)
•4 Corner caps
•Corner cap tool
•2 Silver thumbscrews
•2 Black hex cap machine screws
•2 Black hex cap machine screws
•2.5mm Hex wrench
•3mm Hex wrench
•JL Audio logo badge
•Connection Guide
•Registration card
•Owner's manual
Full-featured Digital Signal Processor
Designed to simplify great audio, every VXi amplifier combines our advanced NexD2™ switching amplifier technology with an integrated, full-featured digital signal processor.
The VX600/1i monoblock subwoofer amplifier outputs up to 400 watts into 4 ohms, or a staggering 600 watts into 2 ohms. A specialized, low-frequency version of our NexD2™ amplifier technology delivers rock-solid bass performance and fidelity, with outstanding efficiency. Compact dimensions with all connections placed on one side, via mating plugs, greatly simplify installation into tight spaces.
Configured via a Compatible External Device
Instead of traditional control knobs and switches, all amplifier adjustments and DSP functionality are configured via a compatible external device (PC, Tablet or Smartphone), with the appropriate JL Audio TüN® Software application installed.
Amplifier includes: Power Connector (for 4 AWG wire), Analog Input/Pre-Out Harness, Subwoofer Output Connector, 6 ft A/B USB Cable
| Brand | JL Audio |
| RMS Power Output (Watts x Channels) | 400 x 1 |
| Peak Power Output (Watts x Channels) | N/A |
| Power at 2 Ohms (Watts x Channels) | 600 x 1 |
| Bridged Power (Watts x Channels) | N/A |
| Minimum Impedance Bridged | N/A |
| Minimum Impedance Unbridged | 2 |
| Minimum Impedance | 2 |
| Amplifier Class | D |
| Low-Pass Crossover Frequency | Via Tun software |
| Low-Pass Slope (dB/octave) | Via Tun software |
| High-Pass Crossover Frequency | N/A |
| High-Pass Slope (dB/octave) | N/A |
| Best Frequency Response | 12-500 Hz |
| THD at Rated RMS Power | 0.01 |
| Signal to Noise Ratio | 64 dB |
| Input Voltage | 14.4v |
| Bass Boost | No |
| Bass Boost Frequency | N/A |
| Fan Cooled | No |
| Fuse Rating | 50 |
| Speaker Level Inputs | Yes |
| Preamp Outputs | 2 |
| Width (inches) | 9 1/16" |
| Height (inches) | 2 1/8" |
| Depth (inches) | 6 3/4" |
| Parts Warranty | 1 Year |
| Labor Warranty | 1 Year |
