We are a JL Audio authorized dealer so you get up-to-date, fully warrantied products.
300-WATT MONOBLOCK AMPLIFIER
This monoblock amplifier is specifically designed to power a subwoofer.
300-WATT 4 CHANNEL AMPLIFIER
This 4 channel amplifier can power up to a maximum of four pairs of speakers or two pairs of speakers and one subwoofer.
600-WATT 6 CHANNEL AMPLIFIER
This staggered-power 6 channel amplifier can power up to a maximum of six pairs of speakers or four pairs of speakers and one subwoofer.
EASY TUNE FEATURE
For additional optimization, pair with a Fusion® stereo with built-in DSP, and download the Fusion® Audio app for selectable profiles. This enables the Easy Tune feature, which streamlines amplifier setup to ensure superior sound quality and system protection.
CLASS-D AMPLIFIER TECHNOLOGY
The highly efficient Class-D design provides lower battery drain with a higher output than Class-AB amplifiers. This delivers increased power to the connected speakers/subwoofers for an enhanced level of audio performance.
RUGGED DESIGN
These amplifiers offer superior levels of durability and are built to IP67 standards (excluding cables) to withstand abuse in harsh marine environments.
| Brand | JL Audio |
| Amplifier Key Features | Bass Boost, Speaker Level Inputs, Weather-Resistant |
| RMS Power @ 2 ohms | 150 watts x 2 channel |
| Series | AP Series |
| Amplifier Class | D |
| Number of Channels | 6-Channel |
| Total RMS Power Output | 600 watts |
| RMS Power @ 4 ohms | 50 watts x 4 channel |
| RMS Power @ 2 ohms | 75 watts x 4 channel |
| Bridged RMS Power | 150 watts x 2 channel |
| RMS Power @ 4 ohms | 100 watts x 2 channel |
| Maximum Input Gauge Size | 4 AWG |
| Minimum Impedance Unbridged | 2 ohm |
| Minimum Impedance Bridged | 4 ohms |
| Frequency Response | 20 - 20000 Hz |
| THD at Rated RMS Power | 0.01 |
| Speaker Level Inputs | Optional (Requires Accessory Adapter) |
| Preamp Outputs | 1 pair |
| Built-in Crossover | Low-Pass (LP), High-Pass (HP), Subsonic |
| High-Pass Crossover Frequency | 20 - 500 Hz |
| Low-Pass Crossover Frequency | 20 - 500 Hz |
| Subsonic Filter | 20 - 50 Hz |
| Signal-to-Noise Ratio | 70 dB |
| Bass Boost | 0 - 18 dB |
| Remote bass/level controller | No |
| Fuse Rating | 70A x 1 |
| Total Fuse Rating | 70 |
| Strappable | No |
| Sonic Certified Amplifier | Not Tested |
| Amp Bluetooth Connectivity | No |
| Hi-Res Certified | No |
| Low-Level Input Sensitivity | 200 mV - 2 volts |
| High-Level Input Sensitivity | 800 mV - 8 volts |
| Parts Warranty | 1 Year |
| Labor Warranty | 1 Year |
