JL Audio 12W0v3-4

JL Audio 12" W0v3 Series 4-Ohm Single Voice Coil Subwoofer
No reviews yet Write a Review
In-Store Pickup | Call Us At 510-527-9888 For Pricing
30 days Free Ground Shipping Inside the US within 48 hours
30 days Free Exchanges Guarantee
30 days Money-Back Guarantee if you are not satified
1 year Manufacture Warranty

We are a JL Audio authorized dealer so you get up-to-date, fully warrantied products.

What's Inside?
• (1) 12" Single voice coil 4-ohm subwoofer
• (1) Owner's manual

rugged car subwoofer
A rugged car subwoofer that can blow you away, the JL Audio 12W0v3-4 can give you the subwoofer performance that you'll never get from others. Though considered an entry-level sub, this 12-inch subwoofer can add some heart-pounding bass that can match many premium subs in the market.

Mica-filled Polypropylene Cone
It has a mica-filled polypropylene cone and a foam surround, which gives the subwoofer the rigidity and durability to withstand the stress that comes from extended hours of usage at cranked-up volume levels while producing an accurate bass response with only minimal distortion.

DMA-optimized Motor Design
It uses JL Audio's DMA-optimized motor design, which helps reduce distortion while producing a clean and punchy low-frequency performance. It also has JL Audio's famous Elevated Frame Cooling design, improving the subwoofer's power handling and allowing it to stay cool for a long time, even used for extended hours at high volume levels. The JL Audio 12W0v3-4 has a power output of 300 Watts RMS and can reach up to 600 Watts of peak power at a 4-ohm impedance. It has a frequency response of 22 up to 250 Hz and a sensitivity rate of 85.64 dB, allowing the subwoofer to go deep and loud with less distortion.

Brand JL Audio
Size 12 -inch
Impedance (Ohms) 4
Cone Material Polypropylene
Surround Material Foam
Port diameter (inches) 3
Port length (inches) 14
Max RMS Power Handling 300
Peak Power Handling (Watts) 600
Top Mount Depth (inches) 5.4375
Bottom Mount Depth (inches) N/A
Cutout Diameter or Length (inches) 10.8125
Free-Air No
Dual Voice Coil No
Sensitivity 85.64 dB at 1 watt
Frequency Response 22 - 250 Hz
Vas (liters) 71.64
Fs (Hz) 28.43
Qts 0.67
Xmax (millimeters) 11.4
Ideal Sealed Box Volume (cubic feet) 1.375
Minimum Sealed Box Volume (cubic feet) N/A
Maximum Sealed Box Volume (cubic feet) N/A
Ideal Ported Box Volume (cubic feet) 1.75
Minimum Ported Box Volume (cubic feet) N/A
Maximum Ported Box Volume (cubic feet) N/A
Parts Warranty 1 Year
Labor Warranty 1 Year
