We are a JL Audio authorized dealer so you get up-to-date, fully warrantied products.
What's Inside?
• (1) 12" Single voice coil 4-ohm subwoofer
• (1) Owner's manual
rugged car subwoofer
A rugged car subwoofer that can blow you away, the JL Audio 12W0v3-4 can give you the subwoofer performance that you'll never get from others. Though considered an entry-level sub, this 12-inch subwoofer can add some heart-pounding bass that can match many premium subs in the market.
Mica-filled Polypropylene Cone
It has a mica-filled polypropylene cone and a foam surround, which gives the subwoofer the rigidity and durability to withstand the stress that comes from extended hours of usage at cranked-up volume levels while producing an accurate bass response with only minimal distortion.
DMA-optimized Motor Design
It uses JL Audio's DMA-optimized motor design, which helps reduce distortion while producing a clean and punchy low-frequency performance. It also has JL Audio's famous Elevated Frame Cooling design, improving the subwoofer's power handling and allowing it to stay cool for a long time, even used for extended hours at high volume levels. The JL Audio 12W0v3-4 has a power output of 300 Watts RMS and can reach up to 600 Watts of peak power at a 4-ohm impedance. It has a frequency response of 22 up to 250 Hz and a sensitivity rate of 85.64 dB, allowing the subwoofer to go deep and loud with less distortion.
Brand | JL Audio |
Size | 12 -inch |
Impedance (Ohms) | 4 |
Cone Material | Polypropylene |
Surround Material | Foam |
Port diameter (inches) | 3 |
Port length (inches) | 14 |
Max RMS Power Handling | 300 |
Peak Power Handling (Watts) | 600 |
Top Mount Depth (inches) | 5.4375 |
Bottom Mount Depth (inches) | N/A |
Cutout Diameter or Length (inches) | 10.8125 |
Free-Air | No |
Dual Voice Coil | No |
Sensitivity | 85.64 dB at 1 watt |
Frequency Response | 22 - 250 Hz |
Vas (liters) | 71.64 |
Fs (Hz) | 28.43 |
Qts | 0.67 |
Xmax (millimeters) | 11.4 |
Ideal Sealed Box Volume (cubic feet) | 1.375 |
Minimum Sealed Box Volume (cubic feet) | N/A |
Maximum Sealed Box Volume (cubic feet) | N/A |
Ideal Ported Box Volume (cubic feet) | 1.75 |
Minimum Ported Box Volume (cubic feet) | N/A |
Maximum Ported Box Volume (cubic feet) | N/A |
Parts Warranty | 1 Year |
Labor Warranty | 1 Year |
