We are a Alpine authorized dealer so you get up-to-date, fully warrantied products.
What's Inside?
•Mono subwoofer amplifier (four 25A ATO fuses installed)2 End caps
•Four 3/4" screws
•Four 1/4" screws
•2.5mm Allen key
•Owner's Manual
Massive Bass Power
Alpine's Next Generation S-Series S2-A120M mono subwoofer amplifier makes it a lot easier to get great bass in your ride, delivering up to 1200 watts RMS power to your sub. A variable bass boost allows you to dial in some extra kick and impact for more low-frequency enjoyment. You can even add an optional wired remote to control the level of bass from your front seat.
More Convenient Features
A low-pass filter puts you in command of the frequency spectrum that reaches your sub. The amp includes preamp- and speaker-level inputs, so you can install it in almost any vehicle, even one with a factory radio. When using the speaker-level inputs, the amp can sense the incoming signal and turn itself on, eliminating the need to run a separate turn-on wire to the receiver or fuse box.
| Brand | Alpine |
| RMS Power Output (Watts x Channels) | 600 x 1 |
| Peak Power Output (Watts x Channels) | N/A |
| Power at 2 Ohms (Watts x Channels) | 1200 x 1 |
| Bridged Power (Watts x Channels) | N/A |
| Minimum Impedance Bridged | N/A |
| Minimum Impedance Unbridged | 1 |
| Minimum Impedance | 1 |
| Amplifier Class | D |
| Low-Pass Crossover Frequency | 50-400 Hz |
| Low-Pass Slope (dB/octave) | 24 dB/octave |
| High-Pass Crossover Frequency | N/A |
| High-Pass Slope (dB/octave) | N/A |
| Best Frequency Response | 10-400Hz Hz |
| THD at Rated RMS Power | 0.01 |
| Signal to Noise Ratio | 85 dB |
| Input Voltage | 14.4v |
| Bass Boost | 0-12 dB |
| Bass Boost Frequency | 50 Hz |
| Fan Cooled | No |
| Fuse Rating | 100 |
| Speaker Level Inputs | Yes |
| Preamp Outputs | 2 |
| Width (inches) | 13 3/4" |
| Height (inches) | 2 1/4" |
| Depth (inches) | 8 5/16" |
| Parts Warranty | 1 Year |
| Labor Warranty | 1 Year |
