We are a Pioneer authorized dealer so you get up-to-date, fully warrantied products.
What's Inside?
• Digital multimedia receiver (10A fuse)
• Wiring harness (6.5' Parking brake wire)
• Preout/AV harness
• Remote control (CXE9605)
• CR2025 3V lithium battery (installed in remote)
• 58" USB extension cable
• Microphone w/ visor-bracket (attached 10' cable terminated by a right-angled 2.5mm connector)
• Double-sided tape
• (6) Pan-head ISO screws (M5 x 9mm)
• (6) 6 Counter-sunk ISO screws (M5 x 9mm)
• Installation Manual
• Quick Start Guide
• Warranty Sheet
Help Your Driving Experience
In upgrading to a new multimedia receiver, you should highly consider if it comes with modern features that could help your driving experience take it to the next level, making it more comfortable for you while you are on the road. For the Pioneer DMH-341EX, not only is it equipped with the latest features, but it is also budget-friendly.
Has a Bluetooth Connectivity Option
The 6.75-inch Pioneer DMH-341EX multimedia receiver has a Bluetooth connectivity option, allowing you to answer phone calls hands-free and stream music wirelessly. Using Pioneer's Weblink app, you can select some apps from your phone using the receiver's touchscreen display. With Pioneer's Vozsis app, you can also use voice commands with Amazon's Alexa.
Built-in MOSFET Amplifier
Although you have the option to connect the Pioneer DMH-341EX receiver with an external car amplifier, it still comes with a built-in MOSFET amplifier of its own, which can handle a power output of 14 Watts RMS and can reach up to 50 Watts of peak power. It has a 5-channel preamp output, where you can connect a pair of front and rear speakers while also connecting a mono sub for a full-range audio experience.
Has a 13-band Graphic EQ
The Pioneer DMH-341EX has a 13-band graphic EQ, so you can shape the amplifier's frequency response and tune it to the acoustics inside of your vehicle. It also has high and low-pass filters, filtering out unwanted frequencies, resulting in a defined audio quality, and protects your subwoofer from blowing off.
| Brand | Pioneer |
| CarPlay | No |
| Android Auto | No |
| Siri Control | No |
| Alexa Voice Control | Y |
| Android Control | Yes |
| AUX Input | Mini (rear) |
| Audio/video Input | Mini (rear) |
| USB Input | Rear |
| USB Port Power | 1.5A |
| Backup Camera Input | Yes |
| Second Camera Input | No |
| Memory Card Slot | USB memory |
| Bluetooth Compatible | Built-in |
| Satellite Radio Ready | No |
| HD Radio | No |
| Navigation | No |
| Full size | No |
| Nano | No |
| Touch | No |
| iPhone | 6 and newer |
| RMS Power (CTA-2006) | 14 watts |
| RMS Power (Manufacturer) | 22 watts |
| Peak Output | 50 watts |
| RMS Power Bandwidth | 20-20kHz |
| Preamp Outputs | 5-channel |
| Sub Preamp Outputs | Yes |
| Switchable Rear Preamp Outputs | No |
| Video Screen | Yes |
| Preamp Voltage | 2 volts |
| Screen Size | 6.75 |
| Screen Type | Swipeable (Capacitive) |
| Key Button Color | Variable |
| EQ Bands | 13 |
| Wireless Remote | Yes |
| Steering Wheel Control Compatible | Adapter required |
| FM Sensitivity | 12 dBf |
| European Tuning | No |
| Seek/Scan | Seek |
| Radio Data System | Yes |
| Music File Playback | MP3, WMA, AAC, FLAC, WAV |
| High-res Playback | FLAC (192kHz) |
| Chassis Depth | 5.605 |
| Chassis Width | 7.015 |
| Chassis Height | 3.945 |
| Parts Warranty | 1 Year |
| Labor Warranty | 1 Year |
