We are a Kenwood authorized dealer so you get up-to-date, fully warrantied products.
What's Inside?
•4-Channel amplifier
•Two 20-amp ATC fuses (installed)
•Terminal cover (installed)
•8" Speaker level input harness
•Four 5/8" Screws
•Owner's Manual
Ultra-high Grade Range Amplifiers
Ultra-high grade range amplifiers and speakers that deliver high density realistic sound and a spatial sound impression. The new X-Series amplifiers are precisely designed for High-Resolution Audio to create a truly authentic listening experience with every detail and nuance.
High-Resolution Audio
High-Resolution Audio is high-quality sound that exceeds CD standard. High-resolution audio captures and beautifully expresses all the details of your favorite music. Through ultra-high and low frequencies, immerse yourself in a rich and high-quality sonic experience
Easier Installation
Detachable sliding terminal cover offers a sleek design and easier installation. Speaker Level Input Harness is included to connect to speaker wires from factory installed receivers.
| Brand | Kenwood |
| RMS Power Output (Watts x Channels) | 50 x 4 |
| Peak Power Output (Watts x Channels) | 150 x 4 |
| Power at 2 Ohms (Watts x Channels) | 75 x 4 |
| Bridged Power (Watts x Channels) | 150 x 2 |
| Amplifier Class | D |
| Low-Pass Crossover Frequency | 50-200 Hz |
| Low-Pass Slope (dB/octave) | 12 dB/octave |
| High-Pass Crossover Frequency | 50-200 Hz |
| High-Pass Slope (dB/octave) | 12 dB/octave |
| Minimum Impedance Bridged | 4 |
| Minimum Impedance Unbridged | 2 |
| Minimum Impedance | 2 |
| Best Frequency Response | 20 50k Hz |
| THD at Rated RMS Power | 0.01 |
| Signal to Noise Ratio | 85 dB |
| Input Voltage | 14.4v |
| Bass Boost | 0-18 dB |
| Bass Boost Frequency | 40 Hz |
| Fan Cooled | No |
| Fuse Rating | 40 |
| Speaker Level Inputs | Yes |
| Preamp Outputs | No |
| Width (inches) | 8 7/16" |
| Height (inches) | 2 1/8" |
| Depth (inches) | 5 15/16" |
| Parts Warranty | 2 Years |
| Labor Warranty | 2 Years |
