JL Audio XD600/1v2 Amplifier

JL Audio 600W RMS x 1 XDv2 Series Class D Mono Car Subwoofer Amplifier
No reviews yet Write a Review
In-Store Pickup | Call Us At 510-527-9888 For Pricing
30 days Free Ground Shipping Inside the US within 48 hours
30 days Free Exchanges Guarantee
30 days Money-Back Guarantee if you are not satified
1 year Manufacture Warranty

We are a JL Audio authorized dealer so you get up-to-date, fully warrantied products.

What's Inside?
•(1) Monoblock amplifier
• Self-adhesive JL Audio badge
• 2.5mm Allen wrench
• Owner's Manual

High-speed NexD™ switching design
This potent monoblock amplifier employs our high-speed NexD™ switching design to achieve unprecedented efficiency and amazing power output in a very compact chassis. Don't let the small size fool you, though... this amplifier is capable of serious subwoofer power, delivering a full 600 W of continuous power into a 2 ohm load (14.4V, 1% THD). Targeted specifically for subwoofer applications, the XD600/1v2 includes a variable slope low-pass filter with continuously variable cutoff frequency selection from 50-500 Hz.

Automatic turn-on capability
The XD600/1v2 also features the v2 Spec feature set, which consists of automatic turn-on capability (via signal sensing or DC-offset sensing), and a dual-range differential-balanced input section able to handle a wide range of input voltage levels. With the addition of an HD-RLC remote level control (sold separately), the amplifier's level can be directly controlled from the driver's seat. This amplifier features a black powder-coat finish and a gasketed, brushed aluminum cover for the controls.

NexD™ Switching Technology
Taking the above into account when designing the NexD™ subwoofer amplifiers, we have taken the simple fixed PWM approach and enhanced it with a very high switching frequency: 240 kHz, which is about 4x higher than most Class D subwoofer amplifiers. This pushes the amplifier's bandwidth to at least 500 Hz with minimal distortion and improves efficiency, while keeping typically bulky circuity more compact. Your subwoofers will reward you with tight, rock-solid bass performance.

Advanced Rollback Protection
Should a JL Audio amplifier equipped with Advanced Rollback Protection reach an unsafe operating temperature, a special circuit rolls back peak power output, without changing gain, until the amplifier cools down to a safe operating temperature. The condition is generally indicated by a red “Thermal” or “Status” LED state. On VXI amplifiers, the LED ring will flash red. Once the amplifier cools down, the circuit restores full peak power output and the indicator reverts to its normal state. The operation of Advanced Rollback Protection is inaudible in most cases, but it ensures that your music keeps on playing, even under the most demanding conditions.

Brand JL Audio
RMS Power Output (Watts x Channels) 400 x 1
Peak Power Output (Watts x Channels) N/A
Power at 2 Ohms (Watts x Channels) 600 x 1
Bridged Power (Watts x Channels) N/A
Minimum Impedance Bridged N/A
Minimum Impedance Unbridged 2
Minimum Impedance 2
Amplifier Class D
Low-Pass Crossover Frequency 50-500 Hz
Low-Pass Slope (dB/octave) 12 or 24 dB/octave
High-Pass Crossover Frequency N/A
High-Pass Slope (dB/octave) N/A
Best Frequency Response 7-500 Hz
THD at Rated RMS Power 0.01
Signal to Noise Ratio 87 dB
Input Voltage 14.4v
Bass Boost No
Bass Boost Frequency N/A
Fan Cooled No
Fuse Rating 50
Speaker Level Inputs Yes
Preamp Outputs 2
Width (inches) 8 9/16"
Height (inches) 2"
Depth (inches) 7 1/8"
Parts Warranty 1 Year
Labor Warranty 1 Year
