We are a JL Audio authorized dealer so you get up-to-date, fully warrantied products.
What's Inside?
•Mono amplifier
•Self-adhesive JL Audio badge
•2.5mm Allen wrench
•Owner's Manual
High-speed Nexd™
This ultra-compact monoblock amplifier employs our high-speed NexD™ switching design to achieve unprecedented efficiency and amazing power output for its size. It is small enough to fit in the tightest space applications, including motorcycles and ATV’s (in a weather-tight compartment).
Brushed Aluminum Cover
Targeted specifically for subwoofer applications, the XD300/1v2 includes a variable slope low-pass filter with continuously variable cutoff frequency selection from 50-500 Hz. This amplifier features a black powder-coat finish and a gasketed, brushed aluminum cover for the controls.
Automatic Turn-on Capability
The XD300/1v2 also features the v2 Spec feature set, which consists of automatic turn-on capability (via signal sensing or DC-offset sensing), and a dual-range differential-balanced input section able to handle a wide range of input voltage levels. With the addition of an HD-RLC remote level control (sold separately), the amplifier's level can be directly controlled from the driver's seat.
| Brand | JL Audio |
| RMS Power Output (Watts x Channels) | 200 x 1 |
| Peak Power Output (Watts x Channels) | N/A |
| Power at 2 Ohms (Watts x Channels) | 300 x 1 |
| Bridged Power (Watts x Channels) | N/A |
| Minimum Impedance Bridged | N/A |
| Minimum Impedance Unbridged | 2 |
| Minimum Impedance | 2 |
| Amplifier Class | D |
| Low-Pass Crossover Frequency | 50-500 Hz |
| Low-Pass Slope (dB/octave) | 12 or 24 dB/octave |
| High-Pass Crossover Frequency | N/A |
| High-Pass Slope (dB/octave) | N/A |
| Best Frequency Response | 1-1000 Hz |
| THD at Rated RMS Power | 0.01 |
| Signal to Noise Ratio | 80 dB |
| Input Voltage | 14.4v |
| Bass Boost | No |
| Bass Boost Frequency | N/A |
| Fan Cooled | No |
| Fuse Rating | 30 |
| Speaker Level Inputs | Yes |
| Preamp Outputs | 2 |
| Width (inches) | 6 7/8" |
| Height (inches) | 2" |
| Depth (inches) | 7 1/8" |
| Parts Warranty | 1 Year |
| Labor Warranty | 1 Year |
