We are a JL Audio authorized dealer so you get up-to-date, fully warrantied products.
What's Inside?
• (2) 5-1/4" 2-way speakers
• (2) Grilles
• (8) Self-tapping screws (#8 x 1-3/16")
• (8) Speed clips
• (2) Crimpable female quick slides (0.205"/5.2mm)
• (2) Crimpable female quick slides (0.11"/2.8mm)
• (2) JL Audio logo grille badges
Owner's Manual
Paper template
The Evolution C2 systems
Belonging to JL Audio's mid-tier speaker lines, the JL Audio C2-525x is a two-way speaker designed to make your car entertainment experience so much better than before. With its full-range capability, you might never have to get separate tweeters and subwoofers anymore.
Vast woofer design
The JL Audio C2-525x's woofer comes with a mica-filled polypropylene cone and a butyl rubber surround, giving the speaker the strength to withstand the stress that comes with long hours of use, especially at high volume levels while also still being able to deliver a clean and accurate bass that you'll surely love.
Silk Dome Tweeter
It also has a silk tweeter with a dome design, allowing it to deliver a bright, natural, and accurate high-frequency performance, and it can be driven with a minimal breakup at high volume levels. JL Audio C2-525x is also equipped with a built-in crossover network, which directs the flow of the frequencies, resulting in a more defined audio reproduction.
Can Go Loud With Minimal Distortion
This two-way speaker can handle a power output of 60 Watts RMS and can reach up to 225 Watts of peak power at 4 ohms. The JL Audio C2-525x has a frequency response of 63 Hz to 22 kHz and a sensitivity rate of 89 dB as well, which means that it can go loud with minimal distortion while giving you an extensive full-range frequency performance.
Brand | JL Audio |
Speaker Size | 5.25 |
Design | 2-way |
Tweeter Design | Dome |
Impedance (Ohms) | 4 |
Tweeter Composition | Silk |
Woofer Composition | Mica-filled Polypropylene |
Woofer Surround | Butyl rubber |
Sensitivity (1W at 1 meter) | 89 |
Sensitivity at 2.83 volts | 92 |
Frequency Response | 63 - 22k Hz |
Minimum RMS Wattage | 15 |
Maximum RMS Wattage | 60 |
Peak Power Handling (Watts) | 225 |
Top-mount Depth (Inches) | 2.5 |
Bottom-mount Depth (Inches) | N/A |
Cutout Diameter or Length (inches) | 4.625 |
Mounting Height (Inches) | 0.495 |
Parts Warranty | 1 Year |
Labor Warranty | 1 Year |
