We are a JL Audio authorized dealer so you get up-to-date, fully warrantied products.
What's Inside?
•13.5" Subwoofer
•Black plastic trim ring
•Owner's manual
Enhance Efficiency
If you have the space, it makes a tremendous sense to maximize your subwoofer system's piston area to enhance efficiency (and output).
It gets even better when the larger driver delivers additional power handling and excursion. For the preceding reasons, the 13W3v3 can be the best choice for those seeking high output with great sound quality at medium power levels.
Enhance Linearity and Reliability
As with the smaller W3v3's, several exclusive JL Audio technologies and proprietary assembly techniques are applied to the 13W3v3 to enhance linearity and reliability. The 13W3v3-2 is best used with amplifier power in the 150W - 600W range and is optimized to operate in a moderate size 1.75 cu. ft. (49.6 l) sealed enclosure, or a 2.5 cu. ft. (70.8 l) ported enclosure.
| Brand | JL Audio |
| Size | 13.5 -inch |
| Impedance (Ohms) | 2 |
| Cone Material | Mineral-filled poly |
| Surround Material | Rubber |
| Port diameter (inches) | N/A |
| Port length (inches) | N/A |
| Max RMS Power Handling | 600 |
| Peak Power Handling (Watts) | 1200 |
| Top Mount Depth (inches) | 7.625 |
| Bottom Mount Depth (inches) | N/A |
| Cutout Diameter or Length (inches) | 12.375 |
| Free-Air | No |
| Dual Voice Coil | No |
| Sensitivity | 87.63 dB at 1 watt |
| Frequency Response | 20 - 200 Hz |
| Vas (liters) | 131.26 |
| Fs (Hz) | 24.7 |
| Qts | 0.504 |
| Xmax (millimeters) | 15.5 |
| Ideal Sealed Box Volume (cubic feet) | 1.75 |
| Minimum Sealed Box Volume (cubic feet) | N/A |
| Maximum Sealed Box Volume (cubic feet) | N/A |
| Ideal Ported Box Volume (cubic feet) | 2.5 |
| Minimum Ported Box Volume (cubic feet) | N/A |
| Maximum Ported Box Volume (cubic feet) | N/A |
| Parts Warranty | 1 Year |
| Labor Warranty | 1 Year |
