We are a JL Audio authorized dealer so you get up-to-date, fully warrantied products.
What's Inside?
•(1) 12" Subwoofer
•Black plastic trim ring
•Owner's manual
Has the Mix of Top-notch Build and Sound Quality
A 12-inch subwoofer designed to deliver a monstrous and precise bass output, the JL Audio 12W3v3-2 is the perfect car subwoofer for your medium-powered amplifier. Made in the USA, the JL Audio 12W3v3-2 has the mix of top-notch build and sound quality that you would love in your car subwoofer.
Has a Polypropylene Cone
The JL Audio 12W3v3-2 has a polypropylene cone and a nitrile-butylene rubber surround, which gives the subwoofer the needed rigidity and durability to withstand the effects of extended usage at high volume levels while producing an accurate bass response with only minimal distortion.
Elevated Frame Cooling Design
Utilizing JL Audio's DMA-optimized motor design, it can help reduce distortion as the JL Audio 12W3v3-2 produces a clean and punchy low-frequency performance. It also uses JL Audio's renowned Elevated Frame Cooling design, which efficiently cools down the subwoofer after long hours of use.
Allows the Subwoofer to Go Deep and Loud
The JL Audio 12W3v3-2 has a power output of 500 Watts RMS and can reach up to 1,000 Watts of peak power at 2 ohms. It has a frequency response of 22 to 200 Hz and a sensitivity rate of 87.15 dB, which allows the subwoofer to go deep and loud with less distortion.
Brand | JL Audio |
Size | 12 -inch |
Impedance (Ohms) | 2 |
Cone Material | Mineral-filled poly |
Surround Material | Rubber |
Port diameter (inches) | N/A |
Port length (inches) | N/A |
Max RMS Power Handling | 500 |
Peak Power Handling (Watts) | N/A |
Top Mount Depth (inches) | 6.625 |
Bottom Mount Depth (inches) | N/A |
Cutout Diameter or Length (inches) | 10.875 |
Free-Air | No |
Dual Voice Coil | No |
Sensitivity | 87.15 dB at 1 watt |
Frequency Response | 22 - 200 Hz |
Vas (liters) | 79.47 |
Fs (Hz) | 27.97 |
Qts | 0.5 |
Xmax (millimeters) | 13 |
Ideal Sealed Box Volume (cubic feet) | 1.25 |
Minimum Sealed Box Volume (cubic feet) | N/A |
Maximum Sealed Box Volume (cubic feet) | N/A |
Ideal Ported Box Volume (cubic feet) | 1.75 |
Minimum Ported Box Volume (cubic feet) | N/A |
Maximum Ported Box Volume (cubic feet) | N/A |
Parts Warranty | 1 Year |
Labor Warranty | 1 Year |
