We are a JL Audio authorized dealer so you get up-to-date, fully warrantied products.
What's Inside?
•One 12" Single 2-ohm voice coil subwoofer
•Black plastic trim ring
•Owner's manual
Company's Patented Technologies
Built using the company's patented technologies from its premium subs, the JL Audio 12W1v3-2 ensures you won't need to spend big to have a subwoofer that can deliver high-quality bass output that you'll never get from an entry-level one.
Polypropylene Cone and Rubber Surround
The JL Audio 12W1v3-2 comes with a polypropylene cone and rubber surround, assuring you of an earth-shaking but accurate bass performance with minimal distortion while having the toughness and durability to withstand long hours of use at high volume levels constantly.
Specifically Designed for an Easy Fit
This 12-inch subwoofer is specifically designed for an easy fit, whether on enclosures or directly inside your vehicle, without sacrificing its sound. The JL Audio 12W1v3-2 utilizes the company's famous Elevated Cooling Frame design, which brings cool air to the subwoofer's voice coil, allowing it to stay cool for a long time after extended periods of usage.
Produce a Continuous Power Output
The JL Audio 12W1v3-2 can produce a continuous power output of 300 Watts and a peak power of 600 Watts at 2 ohms. Its frequency response of 22 to 200 Hz and its sensitivity rate of 85.9 dB allows the subwoofer to give you a deep bass performance while being able to go loud with less distortion.
Brand | JL Audio |
Size | 12 -inch |
Impedance (Ohms) | 2 |
Cone Material | Mica-filled polypropylene |
Surround Material | Rubber |
Port diameter (inches) | N/A |
Port length (inches) | N/A |
Max RMS Power Handling | 300 |
Peak Power Handling (Watts) | 600 |
Top Mount Depth (inches) | 5.4375 |
Bottom Mount Depth (inches) | N/A |
Cutout Diameter or Length (inches) | 10.9375 |
Free-Air | No |
Dual Voice Coil | No |
Sensitivity | 85.9 dB at 1 watt |
Frequency Response | 22 - 200 Hz |
Vas (liters) | 72.04 |
Fs (Hz) | 26.55 |
Qts | 0.521 |
Xmax (millimeters) | 11.4 |
Ideal Sealed Box Volume (cubic feet) | 1.152 |
Minimum Sealed Box Volume (cubic feet) | N/A |
Maximum Sealed Box Volume (cubic feet) | N/A |
Ideal Ported Box Volume (cubic feet) | 1.652 |
Minimum Ported Box Volume (cubic feet) | N/A |
Maximum Ported Box Volume (cubic feet) | N/A |
Parts Warranty | 1 Year |
Labor Warranty | 1 Year |
