Alpine PWE-SB10 10" Powered Subwoofer Wedge Enclosure – 300W RMS Built-In Amplifier
The Alpine PWE-SB10 is a compact 10-inch powered subwoofer wedge enclosure designed to deliver powerful bass performance in a space-saving design. Featuring a built-in 300W RMS amplifier and a 10" subwoofer with a 3Ω voice coil, this all-in-one bass solution provides efficient power matching and dynamic low-frequency output.
Its sealed wedge-style enclosure allows flexible installation in trunks, cargo areas, and behind seats, making it ideal for cars, trucks, and SUVs. With selectable high-level and low-level inputs, an adjustable low-pass filter, and included remote bass control, the PWE-SB10 integrates easily with both factory and aftermarket audio systems.
Key Features
- 10" powered subwoofer wedge enclosure
- Built-in 300W RMS amplifier
- 450W peak power handling
- Compact wedge design for universal installation
- Sealed enclosure for tight, accurate bass
- 3Ω voice coil for efficient power matching
- Selectable high-level and low-level inputs
- Adjustable low-pass filter
- Phase control (0°–180°)
- Remote bass level control included (0–12 dB)\
- Auto turn-on mode
- Carpeted enclosure with black leather wrap
- Embroidered Alpine logo
Performance Specifications
- Subwoofer Size: 10"
- Amplifier Power: 300 Watts RMS / 450 Watts Peak
- Voice Coil Impedance: 3 Ohm
- Frequency Response: 35 Hz – 200 Hz
- Enclosure Type: Sealed
- Low-Pass Filter: 50 Hz – 150 Hz (adjustable)
- Phase Control: 0° – 180°
Connectivity & Controls
- Low-level (RCA) inputs
- High-level speaker inputs
- Auto turn-on mode
- Remote bass level control included
- Side-mounted amplifier terminals for easy connection
Enclosure Design
- Compact wedge-style cabinet
- Carpeted box with black leather wrap
- Anti-vibration construction
- Universal fit for multiple vehicle types
Dimensions & Weight
Product Dimensions:
- Width: 16.75"
- Depth: 13.5"
- Height: 13.33"
- Weight: 30.5 lbs
Included Components
- 10" powered subwoofer enclosure
- RCA input cable
- High-level input harness
- Remote bass control
- Remote control cable (5M)
- Terminal block
- Installation tape
- User manual
Why Choose the Alpine PWE-SB10?
The Alpine PWE-SB10 is an all-in-one powered subwoofer solution designed for easy installation and strong bass performance. With a built-in amplifier, compact wedge enclosure, and flexible input options, it provides a simple upgrade for factory or aftermarket systems.
Perfect for:
- Plug-and-play bass upgrade
- Compact powered subwoofer system
- Factory radio integration
- Trunk or behind-seat installation
| Brand | Alpine |
| Maximum Power | 50 Watts |
| RMS Power Output | 18 Watts |
| Built-in EQ | Yes |
| DIN | 1 |
| Bluetooth | Yes |
| Aux Input | Yes |
| MP3 Playback | Yes |
| WMA Playback | Yes |
| Preamp Outputs | Front, Rear & Sub |
| Receiver Size | Single DIN |
| Radio Type | Digital Audio (does not play discs) |
| Bluetooth Features | Hands-free Calling, Audio Streaming (A2DP), External Microphone |
| Volume Control Type | Knob |
| Anti-Theft Security | Detachable Faceplate |
| Wireless Remote | Alpine RUE-4360 Optional (Accessory and sold separately) |
| Peak Power Output | 50 watts x 4 channel |
| RMS Power Output | 18 watts x 4 channel |
| Preamp RCA Outputs | 3 Sets (6-channel) |
| Dedicated Subwoofer Preamp RCA Output | Yes |
| Built-In Equalizer | 3-Band Parametric Equalizer |
| Display Type | Digital LED Backlit Display |
| Touchscreen | No |
| Display Adjustment | Brightness, Dimmer |
| Display Color | Variable |
| Button Color | Variable |
| Compatible Smartphones | iPhone (iOS), Android |
| iPhone Control | Siri Eyes Free Control, Pandora Control |
| Android Control | Pandora Control |
| Inputs | Auxiliary (Front), USB (Front) |
| Outputs | RCA Audio |
| Steering Wheel Control Compatible | Axxess ASWC-1, Yes (Accessory required and sold separately) |
| AM/FM Tuner | Yes |
| FM Presets | 18 |
| AM Presets | 12 |
| Radio Data System (RDS) | Yes |
| Playback | MP3, WMA, FLAC, AAC |
| Parts Warranty | 1 Year |
| Labor Warranty | 1 Year |
