Alpine PXE-X121-12EV

We are an Alpine authorized dealer so you get up-to-date, fully warrantied products.

What's Inside?
• 12-Channel Car Amplifier with Built-In Hi-Res DSP
• Bluetooth Adapter
• USB cable

Alpine PXE-X121-12EV 12-Channel Hi-Res Digital Sound Processor & Amplifier

The Alpine PXE-X121-12EV is a compact yet powerful 12-channel Hi-Res Digital Sound Processor and Amplifier designed for advanced car audio system integration and precision tuning. Delivering efficient staggered power output and Hi-Res Audio playback at 96kHz/24Bit, this DSP/amp combination provides exceptional sound clarity, phase alignment, and system control in a space-saving design.

Equipped with all-pass filter correction, matrix input summing, and fully adjustable crossovers and EQ, the PXE-X121-12EV allows installers and enthusiasts to fine-tune every channel for optimal performance. With support for high-level, RCA, digital, USB DAC, and Bluetooth® inputs, it integrates seamlessly with factory or aftermarket audio systems.

Key Features

• 12-channel Hi-Res Digital Sound Processor and Amplifier
• Hi-Res Audio playback at 96kHz/24Bit resolution
• Efficient amplifier design for reduced heat and power consumption
• All-pass filter correction for precise phase alignment
• Matrix input summing for seamless factory system integration
• Compact chassis for flexible installation options
• Bluetooth® audio streaming with included external module
• PC tuning software available via Alpine Knowledge Center
• Smartphone tuning app available on the App Store
• Optional RUX-C810 wired controller for volume, sub-level, and preset selection (sold separately)

Audio Processing & Tuning

• 31-band parametric or graphic equalizer per channel
• High-pass filter (HPF), low-pass filter (LPF), and bandpass crossovers for each channel
• Time alignment and advanced DSP control via PC or smartphone software

Connectivity

Inputs:

• 12-channel high-level inputs
• 2-channel RCA inputs
• Optical digital input
• Coaxial digital input
• USB (DAC) input
• HD Bluetooth input

Outputs:

• 10-channel high-level outputs
• 2-channel RCA outputs

Amplifier Power Output (Staggered Power Design)

• 25W RMS x 4 channels
• 50W RMS x 6 channels
• 100W RMS x 2 channels
• Can be run in parallel for 1-channel load at 2 Ohms

Technical Specifications

• Channels: 12-channel input / 12-channel output (10 high level, 2 RCA)
• Sampling Rate: 96kHz / 24Bit
• Equalization: 31-band parametric or graphic EQ
• Crossovers: HPF, LPF, and bandpass per channel
• Software Compatibility: PC and smartphone tuning applications

Why Choose the Alpine PXE-X121-12EV?

The PXE-X121-12EV combines powerful amplification with professional-grade digital sound processing in a single compact unit. Its Hi-Res Audio capability, advanced phase correction, and versatile input options make it ideal for upgrading factory systems or building fully customized multi-speaker audio setups while maintaining efficiency and installation flexibility.
